Planetary Gears

While the WedgeRock Planetary Gear may look unconventional, you are not likely to find a more efficient, self-locking gear operator on the market. The sliding action of conventional worm gear valve operators typically lose more than 65% of the input torque to friction resulting in heat and wear; inherent in the self-locking function, conventional worm gear operators are less than 35% efficient.

In contrast, WedgeRock Planetary Gears provide a rolling action with numerous teeth always in contact and self-centering gear carriages that evenly distribute contact stress resulting in higher efficiencies and an extended, more predictable cycle life – typically providing efficiencies greater than 90%.

Manual or motorized applications, WedgeRock has a planetary gear design for every application. From quarter turn to multi-turn, rising stem thrust applications, subsea or topside, WedgeRock can provide a robust, compact and efficient planetary operator for your application.

Mechanical Spring Return

The WedgeRock RS & RSDR Mechanical Spring Return: Engineered for versatility, it scales from 5,000 to 4,500,000 in-lbs. Whether you need Quarter Turn or Linear configurations, Manual or Electric Operation, this device is tailored to meet your requirements. Boasting High Efficiency Gear design, it’s suitable for diverse environments, from pipelines to subsea. Whether an electric or manual build we ensure optimal performance without hydraulic hassles. Additional highlights include a Positive Lock Mechanism, Low Solenoid Power Consumption, and certifications like Buy America, ATEX, and SIL 3 capability. The RS & RSDR combines robustness with efficiency in actuation.
